SEL ULTIMATE 1SN
SEL ULTIMATE 1SN
Tube: high temperature hydraulic oli resistant special synthetic rubber
Reinforcement: 1 high tensile steel wire braid
Cover: Oil, abrasion and weather resistant special synthetic rubber
Application: for low-medium pressure hydraulic systems in indurstry, compressors and mining where operation temperatures are up to 150o
Temperature range: -50°C to +135°C
| Artikal № | Cena (d.m) | Кoličina (d.m.) | Internal Ø mm | Internal Ø inch | Thickness mm | Working pressure bar | Burst pressure bar | Bending radius mm | Weight kg / m |
| 0106014300 | 5,52 € |
| 6,4 | 1/4 | 13,2 | 225 | 1030 | 100 | 0,235 |
| 0106014500 | 6,44 € |  | 8 | 5/16 | 14,8 | 215 | 970 | 115 | 0,275 |
| 0106014700 | 8,00 € | | 9,5 | 3/8 | 17,2 | 180 | 820 | 130 | 0,35 |
| 0106014900 | 8,93 € |
| 12,7 | 1/2 | 20,4 | 160 | 700 | 180 | 0,435 |
| 0106015100 | 11,17 € |
| 16 | 5/8 | 23,5 | 130 | 600 | 200 | 0,5 |
| 0106015300 | 11,81 € |
| 19 | 3/4 | 27,5 | 105 | 500 | 240 | 0,635 |
| 0106015500 | 17,30 € |
| 25,4 | 1 | 35,4 | 88 | 385 | 300 | 0,935 |
