DexyFlex®
AL female 90˚ elbow fitting with O-ring
AL female 90˚ elbow fitting with O-ring
Characteristics: It is offered also RS version (for thin-walled hose)
Construction: The positions with "*" are construction Rotalock
| Article No. | Price (pcs.) | Quantity (pcs.) | Hose size mm | Hose size inch | Threading | L | L1 | W | H |
| 3220030100 | - | - | 8 | 5/16 | 5/8 - 18 | 72.5 | 42.8 | 19 | 24 |
| 3220030300 | - | - | 10 | 13/32 | 3/4 -16 | 79 | 45.8 | 22 | 30 |
| ********** | - | - | 10 | 13/32 | 7/8 - 14 | 95 | 59 | 27 | 48 |
| ********** | - | - | 10 | 13/32 | 1 - 14 * | 78 | 47.5 | 29 | 33 |
| 3220030500 | 1,97 € |
| 12 | 1/2 | 7/8 - 14 | 92 | 58.3 | 27 | 46.5 |
| ********** | - | - | 12 | 1/2 | 1 - 14 * | 93 | 59.3 | 29 | 39 |
| ********** | - | - | 16 | 5/8 | 7/8 - 14 | 89 | 54 | 27 | 45 |
| ********** | - | - | 16 | 5/8 | 1 - 14 * | 92.5 | 57.5 | 29 | 38 |
| 3220030900 | 4,24 € |
| 16 | 5/8 | 1 1/16 - 14 | 103 | 68 | 32 | 54.5 |
