Elbow female adapter and cutting ring - 10290
Elbow female adapter and cutting ring
Fluids: Watter, compressed air, oils, fluids in general for the hydraulic and pneumatic
Size - Maximum pressure advised
ø 4 - 150 kg/cmq. - 148.4 Bar
ø 6 150 kg/cmq. - 148.4 Bar
ø 8 130 kg/cmq. - 128.6 Bar
ø 10 180 kg/cmq. - 178.1 Bar
ø 12 150 kg/cmq. - 148.4 Bar
ø 14 115 kg/cmq. - 113.3 Bar
ø 16 75 kg/cmq. - 74.2 Bar
ø 18 60 kg/cmq. - 59.4 Bar
ø 22 40 kg/cmq. - 39.6 Bar
| Article No. | Price (pcs.) | Quantity (pcs.) | Tube mm | A | L1 | L2 | CH |
| 0710290040 | 2,48 € |
| 4 | 1/8 | 22 | 18 | 8 |
| 0710290060 | 2,48 € |
| 6 | 1/8 | 23,5 | 18 | 9 |
| 0710290061 | 2,76 € |
| 6 | 1/4 | 24 | 22,5 | 11 |
| 0710290080 | 2,76 € |
| 8 | 1/8 | 28 | 21 | 11 |
| 0710290081 | 3,04 € |
| 8 | 1/4 | 28,5 | 25,5 | 13 |
| 0710290082 | 3,86 € |
| 8 | 3/8 | 29 | 25 | 14 |
| 0710290100 | 3,86 € |
| 10 | 1/4 | 34 | 25 | 13 |
| 0710290101 | 4,42 € |
| 10 | 3/8 | 33 | 25 | 14 |
| 0710290102 | 4,97 € |
| 10 | 1/2 | 33 | 27 | 15 |
| 0710290120 | 5,21 € |
| 12 | 1/4 | 34 | 26 | 14 |
| 0710290121 | 5,21 € |
| 12 | 3/8 | 34 | 26 | 14 |
| 0710290122 | 5,24 € |
| 12 | 1/2 | 33 | 27 | 15 |
| 0710290140 | 6,62 € |
| 14 | 1/2 | 38,5 | 30 | 18 |
| 0710290150 | 6,62 € |
| 15 | 1/2 | 39 | 30 | 18 |
| 0710290160 | 7,73 € |
| 16 | 1/2 | 40 | 30 | 18 |
| 0710290180 | 8,28 € |
| 18 | 1/2 | 42 | 29 | 20 |
| 0710290181 | 8,83 € |
| 18 | 3/4 | 42 | 33,5 | 20 |
